77GHz 4D Imaging Millimeter Wave Radar ARH1 The ARH1 77GHz 4D imaging millimeter wave radar developed and produced by Chuhang Technology Vehicle Regulation Platform can feed back alarm at a high speed. Its product characteristics are comparable to laser radar, and can be applied to L3 and above automatic driving scenarios. The product upgrades the computing platform and RF front-end solution to achieve fast and accurate target differentiation for two targets at the same speed and distance with more accurate angular resolution. Besides, in the aspect of pitching, the target height can be stably obtained by increasing the vertical angle resolution, and the target profile or behavior can be effectively analyzed. This radar is also very competitive in terms of product size. Key advantages: Antenna channel 6T×8R · 6000 point cloud number · Detection range 300m · Height detection · Static identification

77GHz Forward Radar ARF2.31 The ARF2.31 77GHz millimeter wave angle radar developed and produced by Chuhang Technology Vehicle Regulation Platform has a detection degree of FOV±75 degrees and a detection distance of 120m. It can realize advanced driving assistance functions such as BSD (blind spot assist monitoring), LCW (lane change assist warning), DOW (door opening warning), RCTA (rear lateral cross collision alarm), etc. through HMI hardwire alarm and applicable vehicle Ethernet/CAN-FD interface. Key advantages: Antenna channel 4Tx4R ·Detection range 250m ·L2+ higher-order driver assistance functions · ASIL B functional safety certification

77GHz Angle Radar ARC2.31 The ARC2.31 77GHz forward radar developed and produced by Chuhang Technology Vehicle Regulation Platform and its series products have obtained EU CE certification. It adopts four-transmitter and four-receiver antenna channel technology, with FOV of ±75 degrees and detection distance of 150m, which can help smart cars (in the field of passenger cars) realize advanced driving assistance functions such as BSD (blind spot assist monitoring), LCW (lane change assist warning), DOW (door opening warning), RCTA (rear lateral cross collision warning), etc. The product can realize ADAS core functions such as LCW, DOW and BSD when applied to vehicle regulation level. Meanwhile, it can serve smart city with scenario application and cover various travel scenarios such as vehicle-road collaboration (V2X). Key advantages: Antenna channels 4Tx4R ·Detection range 150m ·All-weather operation · Vertical resolution

60GHz Life Detection Radar ARS1 Chuhang Technology is the first manufacturer to realize the research and development of 60Ghz vehicle-level living body detection radar in domestic automobile market. At present, this product has obtained EU CE certification. Starting from the social pain point, the radar responds to international children's traffic safety regulations, and is committed to improving the social situation of children being stranded in the car and accidentally dying, and strives to improve the driving safety experience. The radar can cover the whole area inside the vehicle, with small volume, only 52.1x45x15.4mm, low cost, low power consumption, false alarm rate <1% and 0 false alarm rate, and can realize the second row occupation detection and the third row living body detection of ROA, and the heartbeat and respiration detection of DMS driver. Key advantages: Full area coverage in the car · Small size and easy installation · Low cost and low power consumption · False alarm rate <0.5% · False alarm rate 0.

77GHz Commercial Vehicle Blind Spot Detection Radar ARC2.31 The ARC2.31 77GHz commercial vehicle blind spot detection radar developed and produced by Chuhang Technology Vehicle Regulation Platform adopts antenna channel technology with three transmitters and four receivers, covering a wide angle of 180 degrees, with long detection distance and all-weather working characteristics, which can accurately distinguish static and moving targets, with low false positive and false negative rate, and can assist drivers to timely monitor vehicles, pedestrians, two-wheeled vehicles and obstacles in the blind spot area in front of and behind the vehicle, and give drivers light prompts and buzzer alarms, thus helping the driver better judge the road conditions and make reasonable decisions. It can be installed with tractor, cement mixer, dump truck, van, bus and other vehicles, and can be monitored in the speed range of 0 km/h-80 km/h. Its blind spot detection covers more than two lanes on the side, and it also has excellent functional characteristics such as the monitoring range of the rear blind spot is more than 50 meters, and the early warning accuracy rate is over 99%, which can better escort the intelligent and safe travel of commercial vehicles. Key advantages: 180° detection range · Multi-zone hierarchical detection and alarm strategy · Compliance with UN R151 and R159 regulations
